1968 Harley Sprint 250!

65_ dreamer said:
Did you do another ride immediately after the Melee?!

Always great to see you and Lisa. :)
Click to expand...

This was Melee day 3. Fun riding with you Kalle and Lisa too!

SFMCjohn said:
Kalle has some crazy plan to be there two-up on his ‘48 Chief ...
Click to expand...


Ok so I've been riding the Aermacchi again lately so its getting some more love. I'm planning to "build" a nicer exhaust system for it. I picked up a rough stainless header from Moto Italia and I'm looking at different options for the muffler. Currently leaning towards a "Quieter Core Cone/Reverse Cone" muffler from Cone Engineering. I may need to get some tubing bent to make everything fit properly and I'm still trying to decide on the proper length and shape of the exhaust at the back.

The way the header is routed, if I continue straight and flat the muffler will have to be pretty short or it will hit the swing arm, so I'm thinking I'll have the header bend outwards some and then the muffler will clear everything. I'm thinking the bend will match the profile of the swing arm as it widens from the frame to fit the wheel.
I'm torn about whether I should keep the profile flat (with the exception of the cone itself) or angle it up a little as well. Anyway here are some pics of the header. Any input welcome. Link to Cone Eng slip ons https://www.coneeng.com/pdf/motorcycle/MC-finished-Mufflers.pdf

picture.php

picture.php

picture.php

Last edited:
I cut the muffler off my old exhaust to use as a mock up. I think I've got what I want it to look like. I ordered a muffler off ebay. I think they are the same manufacturer as Cone Engineering as they use the exact same text on ebay as on the Core Eng website but the mufflers are available in more sizes and they are using a different name. I went with a fifteen inch cone/reverse cone quieter core. In the pics below the muffler is actually 12" long but I have it mocked up so the exhaust tip is 14" away from the end of the header pipe to give a 1" overlap. I think it will be close to where the real exhaust will end. The muffler I bought is also 304 brushed stainless. I'll need to have the end of the header bent outward just a bit. I'm excited to see how it looks!
picture.php

picture.php

picture.php

picture.php

Last edited:
me, too

some right-hand Ducati singles pipes exit on left side,
header & beginning of cone crossing under engine,
with visually shorter meg ending early, next to s-arm

The new muffler showed up today, so I loaded up the bike and took it to my local muffler guy and we marked it and put a 15 degree bend in the end of the header. I'm super pleased with how its looking. Next I have to decide if I'm welding the muffler to the header or clamping it, and then I need to make a bracket to attach the muffler to the frame.

The new exhaust is much more quiet, and the bike starts much easier with it. I assume I'm going to lose some top end but we shall see. Hopefully not too much. Here are some pics.

picture.php


picture.php


picture.php

Unfortunately Leslie and Moto Italia just retired. Looks like you have been enjoying your Aermacchi! They are such fun, peppy little bikes

I’ve been neglecting the aermacchi. It’s been sitting for about two years but it’s time to get it going again.

Bought a bike lift yesterday and the aermacchi is on it ready to be cleaned up and for me to finish the exhaust work.

Got the welding done on the exhaust. It all lined up the way I wanted so I'm pretty happy. Need to clean the carb and change the oil before I fire it up so might not happen for a couple days.

Here are some pics.

picture.php


picture.php


picture.php


picture.php

See no photos

Someone should put together a Little Italian Bike ride. I couldn't go unless it was in the East Bay - no trailer:rolleyes

Sounds like a great idea.

There is always Alameda Italian Day. Y'all can go for a ride after the show. Usually a pretty good turnout...

Vape ignition kit showed up today!! Woot!! Might take a bit to get it installed but I’m excited!
picture.php


picture.php

Last edited:
Got the VAPE ignition wired up! I'm impressed with the kit, but the wires were way too long in some spots and not long enough in others, so I had to make some decisions on where to put stuff. Most of the old wiring harness came out, and I'm not going to run a battery in the bike, or an ignition switch. It will be like a dirt bike with no key, which I prefer for the simplicity of it.

I decided to put the cdi, reg/rec and the coil all under the seat and behind the side box. I'll get another box for the other side eventually. The side box used to house the 6v battery and my hour meter. I'll wire the hour meter again, but I'll probably put it somewhere where I can actually see it. Here are some pics of how I set it up. It has a great spark! Need to get 12v lights before I wire them up, but that will be relatively easy to do. Then I have some jetting to do, take it off non-op and ride it! Cant wait! I love this little ride!

I made a plate that bolts to the frame and holds the main components that aren't attached to the engine. It all hides nicely behind the tool box.
picture.php

picture.php

picture.php

picture.php
